Ultrasonic spray coating system
Tool
YPS11B-MB, Hangzhou Success Ultrasonic Equipment Co.,LTD
Applications
- Inhalation toxicology / respiratory toxicology
- Identification of biomarkers
- Drug delivery / inhaled therapeutics
- Nanomaterial / nanoparticle toxicity & safety
- Air pollution / environmental exposure studies
- Smoking / e-cigarette / vaping product testing
- Comparative exposure modes / methodology development
- Dosimetry / deposition quantification studies
- Extended / long-term exposures
- High-throughput / multi-well exposures
- Organotypic / 3D respiratory tissue models
- Mechanistic studies & molecular endpoints
Technical Specifications
| Parameter | Specification |
| Power output | 1,000 – 3,000 W adjustable |
| Ultrasonic frequency | 20 kHz |
| Amplitude / power adjustment | 20 % – 100 % variable |
| Processing capacity | 5 – 10 L (depending on liquid viscosity and probe size) |
| Working mode | Continuous or pulsed operation |
| Cooling system | External water cooling recommended for long-duration operation |
| Probe / horn material | Titanium alloy (Ti‑6Al‑4V) |
| Control system | Digital power controller with LCD interface |
| Display parameters | Power, time, amplitude, and temperature (if equipped with sensor) |
| Application modes | Batch or flow-through with optional circulation cell |
| Protection features | Overload, overtemperature, and no-load protection |
| Input voltage | AC 220 V, 50/60 Hz |
Additional Tools
- Enclosure
- 3-axis system form UMOT
Images
